Description: Total payload mass was 2,034 kg (4,484 lb) : 11 satellites weighing 172 kg each, plus a 142-kg mass simulator. This was the first launch of the upgraded v1.1 variant (later called Falcon 9 Full Thrust), with a 30 percent power increase. Orbcomm had originally agreed to be the third flight of the enhanced-thrust rocket, but the change to the maiden flight position was announced in October 2015. SpaceX received a permit from the FAA to land the booster on solid ground at Cape Canaveral, and succeeded.
- Information:
- Flight number: 25
- Flight date: 12/22/2015
- Static fire: 12/19/2015
- Status: Exitoso
- Bibliography:
Information:
State: Active
Company: SpaceX
First Flight: 2010-06-04
Country: United States
Success Rate: 98%
Description: Falcon 9 is a two-stage rocket designed and manufactured by SpaceX for the reliable and safe transport of satellites and the Dragon spacecraft into orbit.
Details:
- Rocket Details:
- Height: 70 meters / 229.6 feet
- Diameter: 3.7 meters / 12 feet
- Mass: 549054 kg / 1207920 lb
- Stages: 2
- Boosters: 0
- Cost per Launch: $50000000
- Engines:
- Type: merlin
- Version: 1D+
- Layout: octaweb
- Thrust vacuum:
- Engine Loss Max: 2
- Propellant 1: liquid oxygen
- Propellant 2: RP-1 kerosene
- Thrust to Weight: 180.1
- Payload Weights:
- Low Earth Orbit: 22800 kg / 50265 lb
- Geosynchronous Transfer Orbit: 8300 kg / 18300 lb
- Mars Orbit: 4020 kg / 8860 lb
- Landing Legs:
- Number: 4
- Material: carbon fiber
First and Second Stage
| Stage | Thrust vacuum kN/lbf | Reusable | Engines | Fuel Amount Tons | Burn Time Sec |
|---|---|---|---|---|---|
| 1 | 8227 / 1849500 | Yes | 9 | 385 tons | 162 sec |
| 2 | 934 / 210000 | Yes | 1 | 90 tons | 397 sec |
